AL-Scan Myopia Optical Biometer
AL-Scan Myopia Optical Biometer
The Marco AL-Scan Myopia offers fast, easy, and accurate measurements that allow you to better measure and monitor myopia progression for informed treatment decisions. /p>
AL-Scan Myopia Optical Biometer
The Marco AL-Scan Myopia offers fast, easy, and accurate measurements that allow you to better measure and monitor myopia progression for informed treatment decisions. Clear reports and graphs allow for effective communication to parents and demonstration of treatment outcomes.
- Quick, easy, and accurate axial length measurement – perfect for young children
- 3D auto tracking and auto capture measure axial length, keratometry, and pupil size automatically
- Comprehensive patient education resources
- Growth curve showing axial length measurements over time
- Age-matched population comparison
- Expected progression curves
- Integration with refraction data and outdoor/near vision activity levels
- Take-home myopia report
Myopia Management /
AL-Scan
Features:
- Quick, easy, and accurate axial length measurement – perfect for young children
- 3D auto tracking and auto capture measure axial length, keratometry, and pupil size automatically
- Comprehensive patient education resources
- Growth curve showing axial length measurements over time
- Age-matched population comparison
- Expected progression curves
- Integration with refraction data and outdoor/near vision activity levels
- Take-home myopia report
Clinical and scientific literature indicates that axial length is a key parameter for confident treatment decisions when it comes to myopia management.
Quick, easy, and accurate axial length measurement – Essential for successful myopia management
By measuring axial length with Marco’s easy-to-use optical biometer, the progression of myopia can be monitored to allow for appropriate interventions. Assessing refraction data only provides half the picture.
Visualization of myopia progression and treatment efficacy for confident decision making
The AL-Scan Myopia displays measurements over time, allowing clinicians to monitor myopia levels, compare them to an age-matched population, and view the expected progression according to growth curves. Axial length data can be displayed with various items, such as refraction data and the amount of outdoor/near vision activities.
Clear presentation of data for impactful parent education with actionable guidance
The AL-Scan Myopia’s clear reports make it easy for clinicians to educate patients and their parents. Additionally, a take-home Myopia Report allows patients to follow their results over time. This report can facilitate a better understanding of why they need treatments and to make lifestyle changes as necessary.
Simply add the Marco AL-Scan Myopia to your practice and take the first step towards comprehensive myopia management.
AL-Scan Myopia Optical Biometer Specifications
Technical Details
| Axial length | – |
|---|---|
| Measurement range | 14 to 40 mm |
| Display increments | 0.01 mm |
| Measurement accuracy | ±0.05 mm |
| Measurement method | Low-coherence interferometry (LCI) |
| Corneal curvature radius | – |
| Measurement range | 5.00 to 13.00 mm |
| Display increments | 0.01 mm |
| Measurement accuracy | ±0.05 mm |
| Pupil size | – |
| Measurement range | 1 to 10 mm |
| Display increments | 0.1 mm |
| Measurement accuracy | ±0.2 mm |
| Auto tracking | X-Y-Z directions |
| Auto shot | Available |
| Display | Tiltable 8.4-inch color LCD touch screen |
| Printer | Thermal line printer with automatic paper cutter |
| Interface | LAN, USB |
Power
| Power Supply | 100 to 240 V AC, 50/60 Hz |
|---|---|
| Power Consumption | 100 VA |
Dimensions
| Measurements | 283 (W) x 504 (D) x 457 (H) mm / 11.1 (W) x 19.8 (D) x 18.0 (H)” |
|---|---|
| Mass | 21 kg / 46 lbs. |
Myopia Viewer MV-1
| Operating system | Windows 10 Pro 1607 or later (64 bit), Windows 11 Pro Windows Server 2016 Standard (64 bit), Windows Server 2019 Standard (64 bit), Windows Server 2022 (64 bit) |
|---|---|
| Display | 1,280 x 768 or higher |
| Connectable devices that transmit refraction data and BCVA | TONOREF II, ARK-1s, ARK-1a, ARK-1, ARK-F, AR-1s, AR-1a, AR-1, AR-F, ARK-560A, ARK-530A, ARK-510A, AR-360A, AR-330A, AR-310A, HandyRef-K, HandyRef |
