NT-510 Non-Contact Tonometer
The NT-510 Non-Contact Tonometer instrument is easy to use with automatic alignment and measurement. The auto-tracking function allows the tonometer operator to instantly align and focus patient while the auto-measurement function automatically takes tonometry measurements after proper alignment.
NT-510 Non-Contact Tonometer
The NT-510 Non-Contact Tonometer instrument is easy to use with automatic alignment and measurement. The auto-tracking function allows the tonometer operator to instantly align and focus patient while the auto-measurement function automatically takes tonometry measurements after proper alignment. The advanced air puff pulse control produces minimum necessary air pressure for improved patient comfort. Each pulse of air is monitored and adjusted according to IOP measurements for increased accuracy.
- Infinitely adjustable LCD screen accommodates various operator viewing angles
- Motorized patient chinrest provides quick and convenient adjustments
- Safety lock protects against accidental patient contact
- Built-in printer
- Sleek, attractive, modernized design
- Computer interface provides for convenient data transfer
Tonometry /
NT-510 Tonometer
Soft Air Puff Control
Advanced air puff pulse control produces minimum necessary air pressure for comfortable patient measurement. Each pulse of air is monitored and adjusted according to IOP measurements for increased accuracy.
Tilt Screen
Tilting 5.7-inch color LCD infinitely adjustable screen accommodates various operator viewing angles.
An easily adjustable LCD screen accommodates various operator viewing angles while a motorized patient chinrest provides quick and convenient adjustments
Automatic Alignment & Measurement
Auto-tracking function allows the operator to instantly align and focus patient. Automeasurement function automatically takes measurements after proper alignment
Advanced “Soft Air” Puff Control
Advanced air puff pulse control produces minimum necessary air pressure for comfortable patient measurement. Each pulse of air is monitored and adjusted according to IOP measurements for increased accuracy.
NT-510 Non-Contact Tonometer Specs
Technical Details
| Measurement Range | 1–40mm Hg, 1–60mm Hg (selectable) |
|---|---|
| Measurement Unit | 1mm Hg |
| Measurement Mode | Automatic and Manual |
| Working Distance | 11mm |
| Alignment | Automatic vertical alignment with one alignment light and focusing indicator |
| Fixation Target | Internal green fixation LED |
| Chinrest Operation | Motorized up and down |
| Measurement Recordings | Built-in thermal printer (three readings and the average) |
| Monitor Tilting | 5.7-inch color LCD display |
| Other Features | Adjustable safety lock, Automatic air pressure control, and External interface |
Dimensions
| Dimensions | 10.2(w) x 18.9(d) x 17.9(h) inches 260(w) x 481(d) x 457(h)mm |
|---|---|
| Weight | 42 lbs, 19 kg |
Power
| Power Requirement | AC 100-240±10%, 50/60 Hz, 100 VA |
|---|
The advanced air puff pulse control produces minimum necessary air pressure for comfortable patient measurement. Each pulse of air is monitored and adjusted according to IOP measurements for increased accuracy.
