ARK-F Autorefractor & Keratometer

The ARK-F offers a fully automatic operation (auto start, auto chin rest adjust, auto detect, auto X-Y-Z align, auto capture, auto eye transition) with voice command guidance.

ARK-F Autorefractor & Keratometer

The ARK-F is a fully automatic Autorefractor and Keratomer with auto start, auto chin rest adjust, auto detect, auto X-Y-Z align, auto capture, and auto eye transition. Gentle voice command guides staff and patients. There is a wide area of refraction of up to 6 mm and mire rings for keratometry which objectively measures accommodation and captures retro-illumination images. The large 7.0” LCD touch screen has a 360° swivel and tilt capabilities for versatile positioning in corners and against walls. Sharper & clearer images using Super Luminescent Diode (superior to LED). Options include a hand-held remote control for manual measurements and control from an iPad app that provides a 1-to-1 display of the ARK-F screen.

  • SLD technology
  • Double ring technology
  • Automatic pupil (2mm min.) and cornea size
  • Sphere measurement range -30D to +25D
  • Cyl 0.00D to ±12D
  • Auto X, Y, Z eye tracking
  • Accommodation
  • Retro-illumination
  • Tilt and Swivel LCD Screen

Retro Illumination

Captures retro-illumination images

Super Luminescent Diode

Sharper and clearer images using Super Luminescent Diode (superior to LED)

Tilt LCD Screen

Large 7.0” LCD touch screen with 360° swivel & tilt capabilities for versatile positioning in corners/against walls

High Speed Printer

The printer paper can be changed easily. The data sheet is cut by an auto cutter for quick and easy detachment.

Optional Accessories

• Optional hand-held remote control for manual measurements
• Optional control from an iPad app that provides a 1-to-1 display of the ARK-F screen

  • Retro Illumination

    Captures retro-illumination images

  • Super Luminescent Diode

    Sharper and clearer images using Super Luminescent Diode (superior to LED)

  • Tilt LCD Screen

    Large 7.0” LCD touch screen with 360° swivel & tilt capabilities for versatile positioning in corners/against walls

  • High Speed Printer

    The printer paper can be changed easily. The data sheet is cut by an auto cutter for quick and easy detachment.

  • Optional Accessories

    • Optional hand-held remote control for manual measurements
    • Optional control from an iPad app that provides a 1-to-1 display of the ARK-F screen

    Fully automatic operation (auto start, auto chin rest adjust, auto detect, auto X-Y-Z align, auto capture, auto eye transition)

    Super Luminescent Diode (SLD)

    Sharper and clearer images using Super Luminescent Diode (superior to LED).

    Super Luminescent Diode
    Marco ARK-F Autorefractor

    Fully Automatic Measurement

    Fully automatic operation (auto start, auto chin rest adjust, auto detect, auto X-Y-Z align, auto capture, auto eye transition). Voice command guides staff and patients. Manual measurement is also an option.

    The EyeTracking System

    The EyeTracking System provides X, Y, Z axes tracking for superior alignment and focusing. The ARK-F automatically initiates measurement at the optimal alignment.

    Marco ARK-F Autorefractor & Keratometer Eye Tracking System
    Marco ARK-F Autorefractor & Keratometer Accomodation

    Accomodation

    Accomodation testing graphs the accommodation on patients especially with pre-presbyopia symptoms, latent hyperopia and children that have near focusing difficulties.

    Large Pupil Zone Imaging Method

    The large pupil zone imaging method enables the measurement of wider area refraction up to 6 mm diameter and can indicate the difference between the wide area refraction and central area refraction of up to 3.5 mm diameter. These pupil diameters are measured simultaneously. The difference of the measurement allows assessment of the effect of pupil size such as a vision in dim light.

    Marco ARK-F Autorefractor & Keratometer Pupil Zone
    Marco ARK-F Autorefractor Retro Illumination

    Retro Illumination

    The ARK-F Autrefractor/Keratometer features retro-illumination which illustrates media opacity in both the cornea and lens.

    ARK-F Autorefractor & Keratometer Specs

    Technical Details

    Objective Spherical Refractive Error -30.00 to +25.00 D (VD = 12 mm) (0.01/0.12/0.25 D increments)
    Cylindrical Refractive Error 0 to ±12.00 D (0.01/0.12/0.25 D increments)
    Cylinder Axis 0 to 180° (1°/5° increments)
    Minimum Measurable Pupil Diameter ø2 mm
    Corneal Curvature Radius 5.00 to 13.00 mm (0.01 mm increments)
    Corneal Refractive Power 25.96 to 67.50 D (n = 1.3375) (0.01/0.12/0.25 D increments)
    Corneal Cylindrical Power 0 to ±12.00 D (0.01/0.12/0.25 D increments)
    Corneal Cylinder Axis 0 to 180° (1°/5° increments)
    Pupillary Distance Measurement 30 to 85 mm (1 mm increments) (Near point PD: 28 to 80 mm at WD = 40 cm)
    Corneal Size Measurement 1.0 to 14.0 mm (0.1 mm increments)
    Pupil Size Measurement 1.0 to 10.0 mm (0.1 mm increments)
    Accommodation Measurement 0 to 10.00 D (0.01/0.12/0.25 D increments)
    Retro Illumination Image Standard
    Vision Comparison Available with scenery chart
    Auto Tracking Fully automatic 3D tracking (X-Y-Z directions)

    Power

    Power Supply AC 100 to 240 V, 50/60 Hz
    Power Consumption 100 VA

    Dimensions

    Measurements 305 (W) x 492 (D) x 488 (H) mm
    12.0 (W) x 19.4 (D) x 19.2 (H)”
    Mass 20 kg / 44 lbs.
